Single-Stage Building Machine
Builds a complete PCR green tire on one machine — innerliner, sidewall, carcass ply, apexed beads, two belts, cap strip and tread, for…
View Details →PCR Tire Manufacturing Equipment, Including Bead Apex Applying Machines
Pinshun Tire Machinery is a Chinese tire equipment manufacturer. We build horizontal automatic and semi-automatic bead apex applying machines, tire building machines, bead winding machines and cord cutting lines for radial passenger tire plants.
2016
Founded
20,000 m²
Production Workshop
24
Engineers & Technicians
100+
Machines Installed
Tire Manufacturing Equipment
90° Cord Cutting Machine
Perforates, cuts, splices and winds fiber cord fabric into finished carcass ply — 90° cut, ±0.5 mm on width and ±0.1° on angle, at 22 cuts…
View Details →
Two-Stage Building Machine
A matched first-stage and second-stage machine set for 16"–22" PCR radial tires: the first stage builds the carcass, the second shapes it…
View Details →Automatic Bead Apex Machine
Applies extruded triangular rubber apex to steel bead cores, with automatic bead loading, clamping, splicing and take-off. Operators…
View Details →Semi-Auto Apex Applying Machine
Applies extruded apex to steel bead cores with fully automatic splicing — the operator places each bead on the applying disc and removes…
View Details →
Bead Winding Machine
Winds six PCR bead cores per cycle straight from bare wire — let-off, preheating, rubber coating, cooling, accumulation and traverse…
View Details →
White Sidewall Grinding Line
Grinds the white sidewall band on cured tires from 12" to 20" — servo wheel positioning, 80- and 180-grit two-stage grinding, and ducted…
View Details →
Cap Strip Winding Machine
Slits calendered cord fabric into 10–25 mm cap strip and winds it linerless onto 16 or 24 stations at up to 50 m/min, holding ±0.5 mm on…
View Details →BEAD APEX APPLYING MACHINES
Horizontal bead apex machines for PCR tire production
Pinshun manufactures fully automatic and semi-automatic horizontal machines that apply triangular rubber apex profiles to steel tire bead cores. Compare the bead handling tasks, published specifications and factory videos for each configuration.
- Standard bead range: 12–20 inches; a large-size model is available for 16–24 inches.
- Automatic bead loading and take-off on the fully automatic configuration.
- Operator loading and take-off, with automatic apex application and splicing, on the semi-automatic configuration.
Fully automatic machine Semi-automatic machine Compare Chinese manufacturers Read the buyer guide
Specifications shown on this site are Pinshun-published information. Confirm the required bead drawings, compound, output conditions and acceptance criteria with the factory before ordering.
Trusted by Leading Chinese Tire Makers
Linglong TireTercelo Tire GroupWanda Boto TyreZhongce Rubber (ZC Rubber)Yanchang Rubber (Shaanxi Yanchang Petroleum Group)Joyroad
100+ machines running in PCR tire plants across China.
Why Pinshun
In-House R&D & Manufacturing
Our 24 engineers and technicians handle design, R&D and manufacturing in-house.
Custom Non-Standard Engineering
Machines are configured to your tire sizes and process requirements, with optional components available on request.
20,000 m² Own Workshop
Every machine is engineered and built in our own 20,000 m² production workshop in Jiangyin, China.
Direct Factory Pricing & Support
Quotes and support come factory-direct from the manufacturer.
